Part number 80C18-1595
High-quality synthetic rubber material, injection molding, environmental protection and quiet, effective protection of the ground, with plastic cover, anti-tangling
| Part number | 80C18-1595 |
|---|---|
| Type | Swivel Caster |
| Wheel diameter | 125 mm |
| Wheel width | 32 mm |
| Load capacity (3.2 km/h) | 90 kg |
| Overall height | 188 mm |
| Tread material | Rubber |
| Tread sub-type | Synthetic Rubber |
| Wheel body | Synthetic |
| Frame material | Steel |
| Bearing | Ball Bearing |
| Brake | Direction Lock |
| Fitting | Threaded Stem |
| Stem thread × length | M16 × 30 |
| Swivel radius | 132 mm |
| Min working temperature | -15 °C |
| Max working temperature | 60 °C |
| Tread hardness | 75A |
| Tread colour | Grey |
| Frame colour | Blue Zinc |
| Salt-spray rating | 72 h |
| Catalogue lead time | 7 days |
Load ratings are dynamic values to ISO 22883 / EN 12532, which covers applications up to 4 km/h. This rating was measured on a level floor at 3.2 km/h. They do not cover long-term static parking, shock loads or towing faster than 3.2 km/h — send us the application and we will confirm the choice.
Mounting dimensions in mm. Schematic drawing, not to scale.
We reply with price and lead time. Tell us the load per caster, the floor and the operating temperature and we will confirm this is the right caster before you order.
