Name: 4" Threaded Stem Swivel Caster, Stainless Steel Frame, Plastic-core Polyurethane Wheel, M12*25
Brand: SHENPAI
SKU: 20D15-1355

Technical specifications

Part number	20D15-1355
Type	Swivel Caster
Wheel diameter	100 mm
Wheel width	32 mm
Load capacity (4 km/h)	130 kg
Overall height	138 mm
Tread material	Polyurethane
Tread sub-type	Cast PU
Wheel body	Synthetic
Frame material	Stainless Steel
Bearing	Ball Bearing
Brake	No Brake
Fitting	Threaded Stem
Stem thread × length	M12 × 25
Swivel radius	84 mm
Min working temperature	-20 °C
Max working temperature	70 °C
Tread hardness	98A
Tread colour	Black
Frame colour	Stainless
Salt-spray rating	96 h
Gross weight	23.5 kg
Catalogue lead time	3 days

Load ratings are dynamic values tested to ISO 22883 / EN 12532 at 4 km/h on a level floor. They do not cover long-term static parking, shock loads or towing faster than 4 km/h — send us the application and we will confirm the choice.

Mounting drawing

Features

Minimal Swivel Head Play
Non-Marking Tread
Thread Guard
Swivel Head Dust Seal
Low Swivel Resistance
Low Start-Up Resistance
Low Noise

Request a quote for 20D15-1355

We reply with price and lead time. Tell us the load per caster, the floor and the operating temperature and we will confirm this is the right caster before you order.
