Part number 20D08-1355
Injection molded super polyurethane material, locking injection molding, oil-resistant, wear-resistant, environmentally friendly and quiet, effective protection of the floor
| Part number | 20D08-1355 |
|---|---|
| Type | Swivel Caster |
| Wheel diameter | 100 mm |
| Wheel width | 32 mm |
| Load capacity (4 km/h) | 130 kg |
| Overall height | 135 mm |
| Tread material | Polyurethane |
| Tread sub-type | Cast PU |
| Wheel body | Synthetic |
| Frame material | Stainless Steel |
| Bearing | Ball Bearing |
| Brake | Total Lock |
| Fitting | Top Plate |
| Top plate size | 92 × 64 |
| Bolt hole spacing | 73 × 45 |
| Swivel radius | 110 mm |
| Min working temperature | -20 °C |
| Max working temperature | 70 °C |
| Tread hardness | 98A |
| Tread colour | Black |
| Frame colour | Stainless |
| Salt-spray rating | 96 h |
| Gross weight | 24.8 kg |
| Catalogue lead time | 3 days |
Load ratings are dynamic values tested to ISO 22883 / EN 12532 at 4 km/h on a level floor. They do not cover long-term static parking, shock loads or towing faster than 4 km/h — send us the application and we will confirm the choice.
Mounting dimensions in mm. Schematic drawing, not to scale.
We reply with price and lead time. Tell us the load per caster, the floor and the operating temperature and we will confirm this is the right caster before you order.
3" Top Plate Swivel Caster, Stainless Steel Frame, Plastic-core Polyurethane Wheel
3" Top Plate Swivel Caster, Stainless Steel Frame, Plastic-core Polyurethane Wheel, Total Lock Brake
3" Top Plate Fixed Caster, Stainless Steel Frame, Plastic-core Polyurethane Wheel
4" Top Plate Swivel Caster, Stainless Steel Frame, Plastic-core Polyurethane Wheel
