Part number 99B22
| Part number | 99B22 |
|---|---|
| Type | Jack / Brake |
| Wheel diameter | 200 mm |
| Overall height | 210 mm |
| Frame material | Steel |
| Brake | No Brake |
| Fitting | Top Plate |
| Top plate size | 120 × 120 |
| Bolt hole spacing | 92.5 × 92.5 |
| Frame colour | Black |
| Salt-spray rating | 72 h |
| Gross weight | 15.8 kg |
| Catalogue lead time | 15 days |
Load ratings are dynamic values tested to ISO 22883 / EN 12532 at 4 km/h on a level floor. They do not cover long-term static parking, shock loads or towing faster than 4 km/h — send us the application and we will confirm the choice.
Mounting dimensions in mm. Schematic drawing, not to scale.
We reply with price and lead time. Tell us the load per caster, the floor and the operating temperature and we will confirm this is the right caster before you order.
