Part number 42A14-1443
Nylon overall pressure casting molding, high load, wear-resistant, not easy to deform, anti-aging, hydrolysis resistance
| Part number | 42A14-1443 |
|---|---|
| Type | Rigid Caster |
| Wheel diameter | 350 mm |
| Wheel width | 100 mm |
| Load capacity (4 km/h) | 10000 kg |
| Overall height | 462 mm |
| Tread material | Nylon |
| Tread sub-type | Nylon 6 |
| Wheel body | Synthetic |
| Frame material | Steel |
| Bearing | Ball Bearing |
| Brake | No Brake |
| Fitting | Top Plate |
| Top plate size | 280 × 250 |
| Bolt hole spacing | 230 × 200 |
| Min working temperature | -25 °C |
| Max working temperature | 90 °C |
| Tread hardness | 75D |
| Tread colour | White |
| Frame colour | Black |
| Salt-spray rating | 72 h |
| Pieces per carton | 1 |
| Catalogue lead time | 15 days |
Load ratings are dynamic values to ISO 22883 / EN 12532, which covers applications up to 4 km/h. This rating was measured on a level floor at 4 km/h. They do not cover long-term static parking, shock loads or towing faster than 4 km/h — send us the application and we will confirm the choice.
Mounting dimensions in mm. Schematic drawing, not to scale.
We reply with price and lead time. Tell us the load per caster, the floor and the operating temperature and we will confirm this is the right caster before you order.
