Part number 42A01-1433
Cast iron core polyurethane material, water-resistant, wear-resistant, durable, environmentally friendly and quiet, effective protection of the ground
| Part number | 42A01-1433 |
|---|---|
| Type | Swivel Caster |
| Wheel diameter | 150 mm |
| Wheel width | 80 mm |
| Load capacity (4 km/h) | 1500 kg |
| Overall height | 212 mm |
| Tread material | Polyurethane |
| Tread sub-type | Cast PU |
| Wheel body | Metal |
| Frame material | Steel |
| Bearing | Roller Bearing |
| Brake | No Brake |
| Fitting | Top Plate |
| Top plate size | 180 × 140 |
| Bolt hole spacing | 145 × 105 |
| Swivel radius | 141 mm |
| Min working temperature | -30 °C |
| Max working temperature | 80 °C |
| Tread hardness | 95A |
| Tread colour | Brown |
| Frame colour | Black |
| Salt-spray rating | 72 h |
| Catalogue lead time | 15 days |
Load ratings are dynamic values tested to ISO 22883 / EN 12532 at 4 km/h on a level floor. They do not cover long-term static parking, shock loads or towing faster than 4 km/h — send us the application and we will confirm the choice.
Mounting dimensions in mm. Schematic drawing, not to scale.
We reply with price and lead time. Tell us the load per caster, the floor and the operating temperature and we will confirm this is the right caster before you order.
