Part number 40A29-1453
cast iron core made of polyurethane, wear-resistant, durable, high hardness, high loads
| Part number | 40A29-1453 |
|---|---|
| Type | Swivel Caster |
| Wheel diameter | 250 mm |
| Wheel width | 80 mm |
| Load capacity (4 km/h) | 2500 kg |
| Overall height | 310 mm |
| Tread material | Polyurethane |
| Tread sub-type | Cast PU |
| Wheel body | Metal |
| Frame material | Steel |
| Bearing | Ball Bearing |
| Brake | Rear Parking Brake |
| Fitting | Top Plate |
| Top plate size | 180 × 140 |
| Bolt hole spacing | 145 × 105 |
| Swivel radius | 280 mm |
| Min working temperature | -15 °C |
| Max working temperature | 50 °C |
| Tread hardness | 65D |
| Tread colour | Blue |
| Frame colour | Black |
| Salt-spray rating | 72 h |
| Catalogue lead time | 15 days |
Load ratings are dynamic values to ISO 22883 / EN 12532, which covers applications up to 4 km/h. This rating was measured on a level floor at 4 km/h. They do not cover long-term static parking, shock loads or towing faster than 4 km/h — send us the application and we will confirm the choice.
Mounting dimensions in mm. Schematic drawing, not to scale.
We reply with price and lead time. Tell us the load per caster, the floor and the operating temperature and we will confirm this is the right caster before you order.
