Part number 40A21-1167
Cast nylon material, high load bearing, low resistance, not easy to deform, anti-aging, hydrolysis resistance
| Part number | 40A21-1167 |
|---|---|
| Type | Swivel Caster |
| Wheel diameter | 300 mm |
| Wheel width | 80 mm |
| Load capacity (4 km/h) | 3000 kg |
| Overall height | 360 mm |
| Tread material | Nylon |
| Tread sub-type | Nylon 6 |
| Wheel body | Metal |
| Frame material | Steel |
| Bearing | Roller Bearing |
| Brake | Direction Lock |
| Fitting | Top Plate |
| Top plate size | 180 × 140 |
| Bolt hole spacing | 145 × 105 |
| Swivel radius | 225 mm |
| Min working temperature | -25 °C |
| Max working temperature | 90 °C |
| Tread hardness | 75D |
| Tread colour | Blue |
| Frame colour | Black |
| Salt-spray rating | 72 h |
| Gross weight | 35.1 kg |
| Catalogue lead time | 3 days |
Load ratings are dynamic values tested to ISO 22883 / EN 12532 at 4 km/h on a level floor. They do not cover long-term static parking, shock loads or towing faster than 4 km/h — send us the application and we will confirm the choice.
Mounting dimensions in mm. Schematic drawing, not to scale.
We reply with price and lead time. Tell us the load per caster, the floor and the operating temperature and we will confirm this is the right caster before you order.
