Part number 35D06-1473
Precision high-temperature bearing that keeps turning freely when hot, with a reinforced high-temperature nylon wheel rated to 230 °C. Wear-resistant, holds its shape, and resists ageing and hydrolysis.
| Part number | 35D06-1473 |
|---|---|
| Type | Fixed Caster |
| Wheel diameter | 125 mm |
| Wheel width | 44 mm |
| Load capacity (4 km/h) | 300 kg |
| Overall height | 165 mm |
| Tread material | Nylon |
| Tread sub-type | Nylon 6 |
| Wheel body | Synthetic |
| Frame material | Stainless Steel |
| Bearing | Ball Bearing |
| Brake | No Brake |
| Fitting | Top Plate |
| Top plate size | 115 × 102 |
| Bolt hole spacing | 84 × 70 |
| Min working temperature | -20 °C |
| Max working temperature | 230 °C |
| Tread hardness | 75D |
| Tread colour | Black |
| Frame colour | Stainless |
| Salt-spray rating | 96 h |
| Catalogue lead time | 5 days |
Load ratings are dynamic values to ISO 22883 / EN 12532, which covers applications up to 4 km/h. This rating was measured on a level floor at 4 km/h. They do not cover long-term static parking, shock loads or towing faster than 4 km/h — send us the application and we will confirm the choice.
Mounting dimensions in mm. Schematic drawing, not to scale.
We reply with price and lead time. Tell us the load per caster, the floor and the operating temperature and we will confirm this is the right caster before you order.
