Part number 35D-1724S
High-quality synthetic rubber material, injection molding, environmental protection and mute, effective protection of the ground, with stainless steel bearings
| Part number | 35D-1724S |
|---|---|
| Type | Standard Wheel |
| Wheel diameter | 100 mm |
| Wheel width | 50 mm |
| Load capacity (3.2 km/h) | 150 kg |
| Tread material | Rubber |
| Tread sub-type | Synthetic Rubber |
| Wheel body | Synthetic |
| Bearing | Ball Bearing |
| Brake | No Brake |
| Min working temperature | -15 °C |
| Max working temperature | 60 °C |
| Tread hardness | 70A |
| Tread colour | Grey |
| Salt-spray rating | 72 h |
| Catalogue lead time | 5 days |
Load ratings are dynamic values tested to ISO 22883 / EN 12532 at 4 km/h on a level floor. They do not cover long-term static parking, shock loads or towing faster than 4 km/h — send us the application and we will confirm the choice.
We reply with price and lead time. Tell us the load per caster, the floor and the operating temperature and we will confirm this is the right caster before you order.
