Part number 35C29-1155
Polypropylene material, overall injection molding, lightweight, economical and durable, not easy to deform, anti-aging, hydrolysis resistance
| Part number | 35C29-1155 |
|---|---|
| Type | Swivel Caster |
| Wheel diameter | 200 mm |
| Wheel width | 45 mm |
| Load capacity (4 km/h) | 390 kg |
| Overall height | 240 mm |
| Tread material | Nylon |
| Tread sub-type | Polypropylene |
| Wheel body | Synthetic |
| Frame material | Steel |
| Bearing | Ball Bearing |
| Brake | No Brake |
| Fitting | Threaded Stem |
| Stem thread × length | M20 × 32 |
| Swivel radius | 156 mm |
| Min working temperature | -20 °C |
| Max working temperature | 70 °C |
| Tread hardness | 75D |
| Tread colour | White |
| Frame colour | Blue Zinc |
| Salt-spray rating | 72 h |
| Catalogue lead time | 15 days |
Load ratings are dynamic values tested to ISO 22883 / EN 12532 at 4 km/h on a level floor. They do not cover long-term static parking, shock loads or towing faster than 4 km/h — send us the application and we will confirm the choice.
Mounting dimensions in mm. Schematic drawing, not to scale.
We reply with price and lead time. Tell us the load per caster, the floor and the operating temperature and we will confirm this is the right caster before you order.
