Part number 35B-1645
Imported POK nylon material injection molding, high load, wear-resistant, not easy to deform, anti-aging, hydrolysis resistance
| Part number | 35B-1645 |
|---|---|
| Type | Standard Wheel |
| Wheel diameter | 100 mm |
| Wheel width | 46 mm |
| Load capacity (4 km/h) | 450 kg |
| Tread material | Nylon |
| Tread sub-type | Nylon 6 |
| Wheel body | Synthetic |
| Bearing | Ball Bearing |
| Brake | No Brake |
| Min working temperature | -25 °C |
| Max working temperature | 90 °C |
| Tread hardness | 75D |
| Tread colour | White |
| Salt-spray rating | 72 h |
| Gross weight | 31.2 kg |
| Catalogue lead time | 2 days |
Load ratings are dynamic values tested to ISO 22883 / EN 12532 at 4 km/h on a level floor. They do not cover long-term static parking, shock loads or towing faster than 4 km/h — send us the application and we will confirm the choice.
We reply with price and lead time. Tell us the load per caster, the floor and the operating temperature and we will confirm this is the right caster before you order.
