Part number 35A71-1471
Precision high-temperature bearings, high temperature resistance, flexible rotation, enhanced high-temperature resistant nylon material, high temperature resistance of 280 degrees, wear-resistant, not easy to deform, anti-aging, hydrolysis resistant
| Part number | 35A71-1471 |
|---|---|
| Type | Fixed Caster |
| Wheel diameter | 200 mm |
| Wheel width | 44 mm |
| Load capacity (4 km/h) | 430 kg |
| Overall height | 240 mm |
| Tread material | Nylon |
| Tread sub-type | Nylon 6 |
| Wheel body | Synthetic |
| Frame material | Steel |
| Bearing | Ball Bearing |
| Brake | No Brake |
| Fitting | Top Plate |
| Top plate size | 115 × 102 |
| Bolt hole spacing | 84 × 70 |
| Min working temperature | -20 °C |
| Max working temperature | 280 °C |
| Tread hardness | 75D |
| Tread colour | Grey |
| Frame colour | Blue Zinc |
| Salt-spray rating | 72 h |
| Catalogue lead time | 7 days |
Load ratings are dynamic values to ISO 22883 / EN 12532, which covers applications up to 4 km/h. This rating was measured on a level floor at 4 km/h. They do not cover long-term static parking, shock loads or towing faster than 4 km/h — send us the application and we will confirm the choice.
Mounting dimensions in mm. Schematic drawing, not to scale.
We reply with price and lead time. Tell us the load per caster, the floor and the operating temperature and we will confirm this is the right caster before you order.
