Name: 4" Threaded Stem Swivel Caster, Stainless Steel Frame, Plastic-core TPE Wheel, Total Lock Brake, M12*25
Brand: SHENPAI
SKU: 20D16-1377

Technical specifications

Part number	20D16-1377
Type	Swivel Caster
Wheel diameter	100 mm
Wheel width	32 mm
Load capacity (3.2 km/h)	90 kg
Overall height	138 mm
Tread material	Rubber
Tread sub-type	Synthetic Rubber
Wheel body	Synthetic
Frame material	Stainless Steel
Bearing	Ball Bearing
Brake	Total Lock
Fitting	Threaded Stem
Stem thread × length	M12 × 25
Swivel radius	110 mm
Min working temperature	-15 °C
Max working temperature	60 °C
Tread hardness	75A
Tread colour	Brown
Frame colour	Stainless
Salt-spray rating	96 h
Gross weight	23.5 kg
Catalogue lead time	5 days

Load ratings are dynamic values to ISO 22883 / EN 12532, which covers applications up to 4 km/h. This rating was measured on a level floor at 3.2 km/h. They do not cover long-term static parking, shock loads or towing faster than 3.2 km/h — send us the application and we will confirm the choice.

Mounting drawing

Features

Minimal Swivel Head Play
Non-Marking Tread
High-Resilience Tread
Non-Slip Tread
Thread Guard
Swivel Head Dust Seal
Low Swivel Resistance
Low Start-Up Resistance
Low Noise

Request a quote for 20D16-1377

We reply with price and lead time. Tell us the load per caster, the floor and the operating temperature and we will confirm this is the right caster before you order.
