Part number 20D14-1014
注塑聚氨酯材质，锁扣式注塑成型，耐油，耐磨，环保静音，有效保护地面
| Part number | 20D14-1014 |
|---|---|
| Type | Swivel Caster |
| Wheel diameter | 75 mm |
| Wheel width | 30 mm |
| Load capacity (4 km/h) | 105 kg |
| Overall height | 111 mm |
| Tread material | Polyurethane |
| Tread sub-type | Cast PU |
| Wheel body | Synthetic |
| Frame material | Stainless Steel |
| Bearing | Ball Bearing |
| Brake | Rear Parking Brake |
| Fitting | Threaded Stem |
| Stem thread × length | M12 × 25 |
| Swivel radius | 110 mm |
| Min working temperature | -15 °C |
| Max working temperature | 50 °C |
| Tread hardness | 98A |
| Tread colour | Red |
| Frame colour | Stainless |
| Salt-spray rating | 96 h |
| Gross weight | 22.3 kg |
| Catalogue lead time | 3 days |
Load ratings are dynamic values tested to ISO 22883 / EN 12532 at 4 km/h on a level floor. They do not cover long-term static parking, shock loads or towing faster than 4 km/h — send us the application and we will confirm the choice.
Mounting dimensions in mm. Schematic drawing, not to scale.
We reply with price and lead time. Tell us the load per caster, the floor and the operating temperature and we will confirm this is the right caster before you order.
