Part number 20D12-1490
Precision high-temperature bearings, high-temperature resistant, reinforced high-temperature resistant nylon material, high-temperature resistant 230 degrees, wear-resistant, not easy to deform, anti-aging, hydrolysis-resistant
| Part number | 20D12-1490 |
|---|---|
| Type | Fixed Caster |
| Wheel diameter | 125 mm |
| Wheel width | 32 mm |
| Load capacity (4 km/h) | 145 kg |
| Overall height | 160 mm |
| Tread material | Nylon |
| Tread sub-type | Nylon 6 |
| Wheel body | Synthetic |
| Frame material | Stainless Steel |
| Bearing | Ball Bearing |
| Brake | No Brake |
| Fitting | Top Plate |
| Top plate size | 92 × 64 |
| Bolt hole spacing | 73 × 45 |
| Min working temperature | -20 °C |
| Max working temperature | 230 °C |
| Tread hardness | 75D |
| Tread colour | Black |
| Frame colour | Stainless |
| Salt-spray rating | 96 h |
| Catalogue lead time | 3 days |
Load ratings are dynamic values to ISO 22883 / EN 12532, which covers applications up to 4 km/h. This rating was measured on a level floor at 4 km/h. They do not cover long-term static parking, shock loads or towing faster than 4 km/h — send us the application and we will confirm the choice.
Mounting dimensions in mm. Schematic drawing, not to scale.
We reply with price and lead time. Tell us the load per caster, the floor and the operating temperature and we will confirm this is the right caster before you order.
