Part number 10D01-1631
High-quality synthetic rubber material, injection molding, environmental protection and quiet, effective protection of the ground, with plastic cover, anti-tangling
| Part number | 10D01-1631 |
|---|---|
| Type | Swivel Caster |
| Wheel diameter | 40 mm |
| Wheel width | 20 mm |
| Load capacity (3.2 km/h) | 30 kg |
| Overall height | 61 mm |
| Tread material | Rubber |
| Tread sub-type | Synthetic Rubber |
| Wheel body | Synthetic |
| Frame material | Stainless Steel |
| Bearing | Ball Bearing |
| Brake | No Brake |
| Fitting | Top Plate |
| Top plate size | 54 × 44 |
| Bolt hole spacing | 40 × 30 |
| Swivel radius | 46 mm |
| Min working temperature | -15 °C |
| Max working temperature | 60 °C |
| Tread hardness | 85A |
| Tread colour | Grey |
| Frame colour | Stainless |
| Salt-spray rating | 96 h |
| Gross weight | 27.2 kg |
| Catalogue lead time | 7 days |
Load ratings are dynamic values to ISO 22883 / EN 12532, which covers applications up to 4 km/h. This rating was measured on a level floor at 3.2 km/h. They do not cover long-term static parking, shock loads or towing faster than 3.2 km/h — send us the application and we will confirm the choice.
Mounting dimensions in mm. Schematic drawing, not to scale.
We reply with price and lead time. Tell us the load per caster, the floor and the operating temperature and we will confirm this is the right caster before you order.
1.5" Plastic-core TPE Wheel
2" Plastic-core TPE Wheel
1.5" Top Plate Fixed Caster, Stainless Steel Frame, Plastic-core TPE Wheel
