AGV Matching Caster Wheel

The product is suitable for AGV driving wheel and driven wheel. The wheel is made of high-grade polyurethane elastomer.
  • 90A01-1820
  • Shenpai
  • PP
  • <=50 kgs
  • 65 Shore A
  • None
  • -15℃~50℃
Availability:

Product Description


 The product is suitable for AGV driving wheel and driven wheel. The wheel is made of high-grade polyurethane elastomer. It can protect the ground without traces with low noise. A variety of material formulations can meet high speed, wear resistance, anti-static, high load, anti-skid and other different performance requirements. With mature standardized products and a perfect customized process system, the company effectively and rapidly designs and produces the customized products according to customer needs.


AGV Drive Wheel (Hub Fitting)

ModelWheel Dia.(mm)Material HardnessTire Width(mm)No.of Fixing HolesFixing Hole(mm)Load(kg)
ADH-190-50-MMG19092A50512800
ADH-305-80-MMG30592A807162600
ADH-420-100-MMG42092A1009183600
ADH-600-120-MMG60092A12011205000


AGV Drive Wheel (Key Way)

ModelWheel Dia.(mm)Material hardnessTire width(mm)Axle Bore Φ(mm)Hub Groove Length(mm)Hub Groove Heght(mm)Capacity(kg)
ADK-130-50-MMG13092A5020521300
ADK-150-50-MMG15092A5025828.3300
ADK-125-50-MMG12592A5025828.3400
ADK-200-50-MMG20092A5016518.3400


AGV Driven Wheel

ModelWheel Dia.(mm)Material HardnessTire Width(mm)Bearing ModelCapacity(kg)
ADW-120-40-MEA12092A406203800
ADW-160-50-MEA16092A5062041000
ADW-200-60-MEA20092A6062041500
ADW-285-80-MEA28592A8062052200
ADW-354-90-MEA35492A9062062800
ADW-406-100-MEA40692A10062073800
ADW-460-105-MEA46092A10562084600
ADW-525-110-MEA52592A11062085000
ADW-600-120-MEA60092A12062095500
