25A Medium-Heavy Duty Caster (Kingpinless)

It is a representative series with easy steering, reliable brakes and large load range. The products conform to JIS standard and are well received by customers and exported to Japan and Southeast Asia in large quantities.

Matching Wheel: RB on steel plate structure

Wheel Material Code: 25A_RBSF

Diameter：	3"	4"	5"	6"	8"
Capacity：	80KG	130KG	200KG	250KG	320KG

Back To Top

Download Product Sheet

Products ID

Wheel size	Plate swivel	Plate fixed	Plate fixed brake	Plate swivel brake	Plate swivel brake	Threaded stem	Threaded stem brake
3"	25A01-1062	25A03-1062	25A04-1062	25A02-1062
4"	25A10-1063	25A12-1063	25A13-1063	25A11-1063	25A72-1063	25A14-1063	25A15-1063
5"	25A19-1064	25A21-1064	25A22-1064	25A20-1064	25A73-1064	25A23-1064	25A24-1064
6"	25A28-1065	25A30-1065	25A31-1065	25A29-1065	25A74-1065	25A32-1065	25A33-1065
8"	25A37-1066	25A39-1066	25A40-1066	25A38-1066	25A75-1066

Matching Wheel: PU on steel plate structure

Wheel Material Code: 25A_PUSF

Diameter：	3"	4"	5"	6"	8"
Capacity：	120KG	230KG	280KG	330KG	400KG

Back To Top

Download Product Sheet

Products ID

Wheel size	Plate swivel	Plate fixed	Plate fixed brake	Plate swivel brake	Plate swivel brake	Threaded stem	Threaded stem brake
3"	25A01-1052	25A03-1052	25A04-1052	25A02-1052
4"	25A10-1651	25A12-1651	25A13-1651	25A11-1651	25A72-1651	25A14-1651	25A15-1651
5"	25A19-1652	25A21-1652	25A22-1652	25A20-1652	25A73-1652	25A23-1652	25A24-1652
6"	25A28-1653	25A30-1653	25A31-1653	25A29-1653	25A74-1653	25A32-1653	25A33-1653
8"	25A37-1654	25A39-1654	25A40-1654	25A38-1654	25A75-1654

Matching Wheel: RB on steel plate structure

Wheel Material Code: 25A_RBSF

Diameter：	3"	4"	5"	6"	8"
Capacity：	80KG	130KG	200KG	250KG	320KG

Back To Top

Download Product Sheet

Products ID

Wheel size	Plate swivel	Plate fixed	Plate fixed brake	Plate swivel brake	Plate swivel brake	Threaded stem	Threaded stem brake
3"	25A01-1067	25A03-1067	25A04-1067	25A02-1067
4"	25A10-1068	25A12-1068	25A13-1068	25A11-1068	25A72-1068	25A14-1068	25A15-1068
5"	25A19-1069	25A21-1069	25A22-1069	25A20-1069	25A73-1069	25A23-1069	25A24-1069
6"	25A28-1070	25A30-1070	25A31-1070	25A29-1070	25A74-1070	25A32-1070	25A33-1070
8"	25A37-1071	25A39-1071	25A40-1071	25A38-1071	25A75-1071

Matching Wheel: NL on steel plate structure

Wheel Material Code: 25A_NLSF

Diameter：	3"	4"	5"	6"	8"
Capacity：	150KG	280KG	350KG	450KG	550KG

Back To Top

Download Product Sheet

Products ID

Wheel size	Plate swivel	Plate fixed	Plate fixed brake	Plate swivel brake	Plate swivel brake	Threaded stem	Threaded stem brake
3"	25A01-1057	25A03-1057	25A04-1057	25A02-1057
4"	25A10-1676	25A12-1676	25A13-1676	25A11-1676	25A72-1676	25A14-1676	25A15-1676
5"	25A19-1677	25A21-1677	25A22-1677	25A20-1677	25A73-1677	25A23-1677	25A24-1677
6"	25A28-1678	25A30-1678	25A31-1678	25A29-1678	25A74-1678	25A32-1678	25A33-1678
8"	25A37-1679	25A39-1679	25A40-1679	25A38-1679
